Cone Incense Making Machine

FULL AUTOMATIC CONE INCENSE MAKING MACHINE

Strong Features
  • The machine uses PLC technology combined with 2 inverters using programming according to each cycle and has an overload alarm system to protect motor safety.
  • The machine can make many bud patterns with different sizes and colors
  • Fill the powder into the hopper continuously and the machine runs in full automatic
  • Can make 2 types of incense buds: with holes and without holes
Price and Status
Giá :
Suport Mobile
  • Di động:

FULL AUTOMATIC CONE INCENSE MAKING MACHINE



I. INTRODUCTION OF FULL AUTOMATIC CONE INCENSE MAKING MACHINE


- Full automatic cone incense making machine  is designed and manufactured by Hai Lan Company team.
- Full automatic cone incense making machine only needs 1 person to operate, saving labor costs.
- Full automatic cone incense making machine can make buds with different colors and sizes.
- Full automatic cone incense making machine can make incense with the following sizes:
+ Diameter: 10-15mm
+ Height: 20-40mm


II. SPECIAL CHARACTERISTICS OF FULL AUTOMATIC CONE INCENSE MAKING MACHINE


- Full automatic cone incense making machine uses PLC technology combined with 2 programmable inverters for each cycle and has an overload alarm system to protect motor safety.
- Powder is continuously poured into the hopper and the machine will run fully automatically
- Can make 2 types of buds: with holes and without holes
- Easy to operate and easy to change the desired incense size


III. TECHNICAL INFORMATION :



Model CIMF-23AT
Weight  273kg
Weight with pallet 313kg
Dimensions 90x60x160cm
Dimensions with pallet 86x67x175cm
Motor power 1.1kw+0.75kw
Power Supply  220V (1 phase)
Processor 60-70 buds/min
Type of incense can make  - Diameter : 10-15mm
- Height: 20-40mm
Color

Can be made in different color.



- Customers can set the required size in the range of:
+ Diameter of bud bottom: 10-15mm
+ Height of buds: 20-40mm

IV. ACCESSORIES INCLUDED :

- 1 stainless steel trough to collect buds
- 1 set of bud needles
- 1 bud hole punching needle
- 1 Cale 19 + 17
- 1 hexagon 3-4-6-8
- 1 sensor
- Comes with 1 set of cylinder-piston
- Comes with 2 sets of molds (1 set according to the machine and 1 set separately)

V. MODE OF SHIPPING :

- Free shipping to customer's place
- Hai Lan technician will come to the place to install and hand over the entire machine process to the customer
